Gen3, Native 4K D-ILA Device

The third-generation 0.69-inch native 4K D-ILA device offers the native contrast ratio of 100,000:1. Also, improvements in the manufacturing process resulted in improved screen uniformity for enhanced image quality.

2,700lm BLU-Escent Laser

JVC’s original BLU-Escent Laser light source has been optimized to achieve exceptional peak brightness of 2,700 lumens with longevity of 20,000 hours. Housed in a compact casing, the laser light engine provides higher output, greater efficiency, and quieter operation, making it an excellent solution for demanding home theater installations.

Pixel Perfect 8K Out with 8K/e-shiftX

Whether the source is 4K or 8K, the latest Gen2 8K/e-shiftX high-resolution display technology uses a 240Hz driver with 4-way, multi-axis shift to flash the screen four times to deliver pixel perfect 8K resolution.

All-glass, All-aluminum Lens System

The 65 mm lens system with 17-element, 15-group all-glass lens projects high-resolution images to every corner of the screen, while securing wide shift ranges of 80% vertically and 34% horizontally to enable faithful reproduction of distortion-free 8K images.

Gen2 Frame Adapt HDR offers Deeper Blacks and More

The 2nd generation Frame Adapt HDR function instantaneously analyzes the different peak brightness per scene or per frame for HDR10 content and performs real-time tone mapping for optimized brightness, color and details. When combined with each of the following modes including the new Deep Black function, the projector detects and analyzes data contained in HDR sources to project the best of what each source has to offer:

Deep Black function subdues tones in dark areas for more realistic darkness.
DML (Display Mastering Luminance) adjusts/sets the dynamic range to match the image for a much better HDR experience.
FILMMAKER MODE™ recreates picture quality that is faithful to the original master.

Picture Mode “Vivid”

Made to reproduce SDR content with a narrow dynamic range in more saturated colors with greater vividness, the Vivid mode is excellent for SDR animated works and gaming CGs.

Dual 48Gbps HDMI Inputs – 8K/60p and 4K/120p

Full 8K input is enabled with 48Gbps 8K/60p HDMI input with HDCP 2.3. Also, 4K120p input that is used with Low Latency Mode is excellent for high frame-rate gaming platforms.

Key Features

Proprietary, Gen3, 0.69-inch Native 4K D-ILA Devices (x3)
2,700-lumen BLU-Escent Laser phosphor light engine
Pixel perfect – Gen2 8K/e-shiftX with New 8K Scaling Engine featuring 4-way, multi-axis shift yields 8,192- x 4,320-pixel projection
100,000:1 native contrast, ∞ (infinite):1 dynamic contrast ratios delivers images brimming with reality
101-step Laser Light Control by slider adjustment
65 mm All-glass Lens with 2X zoom, 80% vertical, 34% horizontal shift
High-contrast Optical Block
Two 48Gbps HDMI/HDCP 2.3 inputs – 8K/60p and 4K/120p
Gen2 Frame Adapt HDR dynamic tone mapping with Theater Optimizer
New Deep Black function extends dark tones with far greater contrast
HDR10+ compatibility
DML (Display Mastering Luminance) adjusts/sets the dynamic range for better HDR experience
Picture mode “Vivid” for projecting animated works and game CGs in SDR format
Wide Color Gamut with Cinema Filter (over 100% DCI-P3)
Built with hand-selected components
Installation Mode with 10 customizable presets
ISF Certified, plus JVC Auto Calibration
Clear Motion Drive for the smoothest video
Multiple Pixel Control (MPC) for increased sharpness and detail
Low Latency Mode effective when displaying high frame-rate gaming content
Controls: Control4 SDDP, LAN, RS-232C, IR, 12V screen trigger out, 3D sync out
3-year Warranty with first year advanced replacement
